Pro TI-9 Thermal Imager Module for Smartphones
₹33,750.00 including GST @18%
New Launch!
Thermal Imager module for Android Smartphones, measures -15°C～600°C, Accuracy: ±2°C or ±2% of reading (whichever is greater), IR Resolution: 256×192 px, Spectral Range: 8～14 μm, Refresh Rate: 25Hz. Photos & Videos supported, user-settable Emissivity, Smartphone App with built-in Analysis, IP54 splash & dust proof.
- Description
- Additional information
- SPECIFICATIONS
- CATALOGUE
- Reviews (0)
Description
New Launch!!
The Metravi Pro TI-9 Thermal Imager Module for Smartphones uses an industrial-grade thermal detector with small pixel spacing and high resolution, and is equipped with a 3.2 mm lens. It is a high-precision and fast-response portable thermal imaging analyser.
Turn Your Smartphone into a Powerful Thermal Inspection Tool!
The Metravi Pro TI-9 Thermal Imager Module for Smartphones is lightweight, portable, plug-and-play, and with a customised, professional-grade thermal imaging analysis APP, it can be connected to an Android phone to conduct infrared observation and temperature measurement of target objects.
Features:
- High-quality optical lenses: paired with high-resolution to achieve excellent imaging effects
- Wide temperature measurement range: -15°C ~ 600°C (5°F ~ 1112°F)
- Alarms: High temperature alarm and customised alarm thresholds
- Display of customised temperature range screens
- High and low temperature tracking
- MetraTherm App with built-in Analysis: adding points, lines, and rectangular frames for regional temperature measurement. Lines and rectangular frames support high and low temperature tracking and high temperature alarms
- Offline analysis of points, lines and rectangular frames after taking pictures
- Supports temperature-locked observation, focusing only on images in a fixed temperature range
Perfect for Multiple Applications
- Electrical inspections and fault detection
- Building diagnostics and energy loss checks
- Mechanical equipment monitoring
- HVAC troubleshooting
- Automotive and PCB diagnostics
- Fire prevention and safety audits
Additional information
| Brand | |
|---|---|
| Colour | |
| Model | |
| Warranty | |
| Temperature Accuracy | 2℃ or ±2% of reading, whichever is greater, -15°C ～ 600°C |
| IR Resolution | 256×192 px |
| Spectral Range | 8～14 μm |
| Spectral Response | |
| Emissivity | |
| Field of View (FoV) | 56° x 42° |
| Colour Palette | Iron, White Hot, Black Hot, Rainbow, Red Hot, Cool Blue |
| Videos | Supported; saved on Smartphone memory |
| Photographs | Supported; saved on Smartphone memory |
| Settings | Thermal imaging professional parameter configuration; temperature unit (°C / °F / °K); language; high temperature alarm; video sound on/of |
| Protection | IP54 Splash-proof and dustproo |
| App Functions | Offline Analysis. Line, Point and Rectangular Frame Analysis. High temperature quick check. Live image flipping. Image editing. |
- Temperature Measurement Range: -15°C ~ 600°C
- Accuracy: ±2°C or ±2% of reading, whichever is greater
- IR Resolution: 256×192 px
- Spectral Range: 8~14 μm
- Refresh Rate: 25Hz
- NETD / Spectral Response: <50mK @25°C
- Emissivity: User-settable; 0.01 to 1.00
- Lens: 3.2mm
- FoV: 56° × 42°
- Interface: C-type USB for Android Smartphones only
- MetraTherm Mobile App Functions:
- Temperature measurements
- Automatic tracking of high and low temperatures
- Center point temperature measurement
- Point temperature measurement
- Regional temperature measurement
- Line temperature measurement
- Temperature range viewing
- Offline Analysis
- Line, Point and Rectangular Frame Analysis
- High temperature quick check
- Live image flipping
- Image editing
- Colour Palettes: Iron, White Hot, Black Hot, Rainbow, Red Hot, Cool Blue
- Photographs: Supported; saved on Smartphone memory
- Videos: Supported; saved on Smartphone memory
- Settings Available:
- Thermal imaging professional parameter configuration
- Temperature unit (°C / °F / °K)
- Language: Supports English, French, German, Spanish, Portuguese, Italian, Russian, Japanese, Korean and Chinese
- High temperature alarm
- Video sound on/off
- Protection: IP54 Splash-proof and dustproof
View Catalogue: Metravi PRO TI-9 Thermal Imager Module for Smartphones Catalogue
